RR-CirKits
is your best source for NMRA LCC compliant products.
NEW!
- Tower LCC
- Support for 16 Input/Output lines.
- Includes drive for any combination of:
- Up to 16 Input Lines.
- Up to 16 Output Lines.
- New Internal Logic Engine with 4032
characters of logic statements.
- Communicates over the CAN bus version of LCC.
- CDI controlled configuration via Software.
(e.g. JMRI DecoderPro 5.6 or later.) Both reading and writing
of description values is directly supported.
- All configuration is stored internally in the nodes, and may
be changed at any time on any system. (no local files to keep up
to date)
- Automatically saves all data including
input/output states during power down.
- Boot Loader protocol allows firmware upgrades
over the LCC Bus connection.
- Power is supplied over the LCC Bus.
- LCC-LocoNet
Gateway image
- Manual
- Add LCC nodes to an existing LocoNet layout.
- Add LocoNet devices to an LCC controlled layout.
- Supports up to 1024 Input/Output conversion pairs.
- Includes an internal NMRA CAN bus LCC® to USB interface. (no
external LCC Buffer-USB required)
- 2,500 Volt High Speed Digital isolation between LCC®
CAN bus, LocoNet®, and USB port.
- Type B USB connector for PC connection.
- Dual RJ45 connectors for easy CAN bus LCC® loop through
connections.
- Dual RJ12 LocoNet connectors for easy LocoNet® loop through
connections.
- 4 LED display status. (Sync, USB, Data, and On)
- Small package size. Just 2-7/16" x 3-5/16" x 1-1/8".
- Ready to run unit includes USB cable, LocoNet cable, LCC
Terminators, and 15V power supply. – Nothing extra to purchase.
- Standard 125,000 Baud CAN bus LCC interface speed. – No
jumpers or switches to set.
- Buffered inputs and outputs for full speed, error free data
transmission.
- Powered directly from LCC®
bus connections* and USB port, or else
create a powered LCC bus using
the unit and power supply.
- Includes optional stand alone LocoNet circuitry.
*Note:
Requires a powered LCC bus. [50 mA. bus load]
- Signal
LCC image
- Support for 16
signal lamps plus 8 I/O lines.
- Each signal mast may use as many lamps as
required.
- Available with signal connections using
miniature screw terminals (-S) or 10 pin headers. (-P)
- Support for 8 Input/Output lines.
- I/O lines includes drive for any combination
of:
- Up to 8 Input Lines.
- Up to 8 Output Lines.
- Internal Logic Blocks with up to 32
conditional statements.
- Up to 8 virtual track circuits for easy linking
to other signal masts.
- Communicates over the CAN bus version of LCC.
- CDI controlled configuration via Software.
(e.g. JMRI DecoderPro 4.8 or later.) Both reading and writing
of description values is directly supported.
- All configuration is stored internally in the nodes, and may
be changed at any time on any system. (no local files to keep up
to date)
- Automatically saves all data including
input/output states during power down.
- Boot Loader protocol allows firmware upgrades
over the LCC Bus connection.
- Power is supplied over the LCC Bus.
LCC Buffer-USB
- LCC
Buffer-USB
- NMRA
CAN bus LCC® to USB interface.
- 2,500 Volt High Speed Digital isolation between CAN bus LCC®
and USB port.
- Simplify your
LCC configuration and/or use a PC based CTC.
- Compatible with JMRI OpenLCB.
- Type B USB
connector for PC connection.
- Dual RJ45
connectors for easy CAN bus LCC®
loop through connections.
- 4 LED display
status. (Ready, Power, Transmit, and Receive)
- Small package
size. Just 1-1/2" x 2-1/4" x ¾".
- Ready to run
unit includes USB cable. – Nothing extra to purchase.
- Standard 125,000
Baud CAN bus LCC interface speed. – No jumpers or switches to
set.
- Buffered inputs
and outputs for full speed, error free data transmission.
- Powered directly
from LCC®
bus connections* and USB port.
*Note:
Requires a powered LCC bus. [10 ma. bus load]
LCC Repeater
- LCC
Repeater image
- Bit
level repeater connects two LCC ® CAN bus segments.
- Quad RJ45 connectors for dual LCC ® CAN bus loop through
connections.
- Includes a CAN bus data monitor LED for network trouble
shooting. 2 LED display.
- Small package size. Just 2-1/2" x 3-1/2" x 1". (including
mounting flanges)
- 600 ma power supplied to each LCC ® CAN bus segment.
- 15VDC 1.2 Amp Universal Switching Power Supply included.
LCC Terminator Pair
- LCC
Terminator image
- NMRA CAN bus LCC® Termination Pair.
- May be used to provide the required termination at each
end of the CAN bus LCC®
- Balanced
CAN
termination provides
the best noise rejection.
- Includes
CAN bus Power Indicator and CAN bus data monitor for
easy network cable trouble shooting.
LCC Power-Point
- LCC Power-Point Image
- LCC Power-Point ties
together 2 LCC jacks, a Traffic Monitor, and a power
supply.
- Create a powered LCC bus for
simple wiring by powering
your LCC Nodes over the cable.
- The LCC Power-Point supplies
1/2A to each LCC CAN Bus cable.
- PS-S-15-1200 universal
switching power supply is included. (Terminator and CAN bus cable shown
are not included)
- Additional
Power-Point
units may be added as required by your system's power
requirements.
LCC® is a trademark of the NMRA
- Next Generation USB to
LocoNet® interface with type A USB
connector.
- Plug and play for Linux, Mac, Windows 10 & 11.
- 2,500 Volt Digital isolator between USB and LocoNet®
- Keep your system up
and running through ground loops, spikes, and surges. Rogue
currents and ground issues can wreak havoc with your data, and
even damage your LocoNet.
- Buffered inputs and outputs allow use with all operating
systems with USB support.
- More robust output design, reduced sensitivity to wiring
errors.
- Even smaller (dongle style) package size. Now just 2" x 1" x
5/8"
Digital Isolation: Your best investment — Keep your system up
and running through ground loops, spikes, and surges.
LocoBuffer-USB
drivers (Driver download not required for
LocoBuffer-NG)
Now
includes beta drivers for Mac Big Sur.
|
